2 x 2 parallel siphons with multiple bends

Fast installation with least possible downtime.

System

Rehab

Medium

Water

Application area

Utility

Line type

Culvert

Country

Slovakia

Region

Nitra

Situation

A total of four siphons through two dams on each side of the river Waag had to be rehabilitated. The siphon rehabilitation was par of a larger renovation project near the village of Vlčany.

Special features

Reintegration of valves

The existing air valves on top of the dams had to be reintegrated after renovation.

Large number of bends

A total of 16 bends with 45° each had to be passed through.

Technical details

Material of host pipe

Steel

Diameter of host pipe

DN 500

Transported fluid

Potable water

Operating pressure

5 to 6 bar

Total length

235 m

Number of sections

8 sections

Number of bends

16 bends of 45° each

Installation time

2 weeks including CCTV and cleaning

Why Primus Line?

High flexibility and bendability for passing through bends of up to 45°

Small installation footprint by using existing chambers or small excavation pits
