DN 400 reinforced concrete pressure pipe

Minimal impact on the city’s everyday activities

System

Rehab

Medium

Water

Application area

Utility

Line type

Transport line

Country

Chile

Region

Santiago de Chile

Situation

Aguas Andinas provides the water supply and sewerage services for most of Santiago de Chile. They operate a network of pipelines that in some cases have been in service for more than 50 years. A great deal of this network consists of reinforced concrete pressure pipes, a technology that was first used in the 1900’s. The poor condition of the system causes water leakage of up to 40%.

Special features

Parallel rehabilitation

of two sections

Perfect team work

by installation partners Outer and Fluvius as well as technical staff of Primus Line who supervised the job

Technical details

Material of host pipe

Reinforced concrete pressure pipe, non-cylinder type

Diameter of host pipe

DN 400

Transported fluid

Potable water

Operating pressure

5 bar

Total length

1,650 m

Number of sections

7 installation sections with 81, 2 x 232, 2 x 351, 88 and 315 m

Number of bends

none

Installation time

4 months (due to city permits only valid for a few days at a time)

Why Primus Line®?

Difficult access for rigid pipes

No digging is needed with Primus Line®

No need of heavy machinery or equipment

Minimal disruption of everyday activities in the city

Need to finish liner insertion of every section within 12 hours
